Yhzs25 25cbm/H mobile batching machine with chassis

Installation Video of mobile batching machine:micfocus.en.made-in-china.comWhy would our clients choose FOCUS Mobile batching machine?FOCUS MACHINERY boasts an award-wining mobile batching machine product range with capacity from 25cbm to 75cbm hourly.Sizes of mobile batching machine:YHZS25(25m3/h),

Featured Products

Installation Video of mobile batching machine:
micfocus.en.made-in-china.com
Why would our clients choose FOCUS Mobile batching machine?
FOCUS MACHINERY boasts an award-wining mobile batching machine product range with capacity from 25cbm to 75cbm hourly.
Sizes of
mobile batching machine:YHZS25(25m3/h), YHZS35(35m3/h), YHZS50(50-60m3/h), YHZS75(75m3/h).

This series of mobile batching machine adopts semi-pulling structure with running system and equipped with standard coupling pin, hence can be dragged by a tractor at the maximum speed of 40km/h.
As uniquely and compactly designed it is, this
mobile batching machine assembles whole functions of accurate material weighing, efficient aggregate conveying, homogeneous mixing, computer auto-controlling and trailing. It is the ideal concrete plant for projects that require frequent removal from one site to another.
Yhzs25 25cbm/H Mobile Batching Machine with Chassis

What are the main features of FOCUS mobile batching machine?
1. Complete mobile unit:
Unit easily transported on-site as well as from project to project, on-board hydraulic system changes plant from travel mode to full operational within 2-3 hours for this
mobile batching machine.
2. Reliability of mix consistency:
Computer and manual dual control mode can be converted easily by a simple switch, twin-shaft mixer offers this
mobile batching machine a consistent high grade of evenly mixed material, with its good quality mixing blades, paddles, arms and liners.
3. Highly precise dosing of water, cement, fly-ash, additive
Focus
mobile batching machine dosing is realized by three-point suspension sensors, and they are all metered separately.
4. Optimized and modular design
FOCUS
mobile batching machine is convenient either for container transport or for towing vehicles.

Installation of Mobile Concrete Beton Plant in Algeria in Sept. 2014:
Yhzs25 25cbm/H Mobile Batching Machine with Chassis
Yhzs25 25cbm/H Mobile Batching Machine with Chassis

ModelYHZS25YHZS35YHZS50/60YHZS75
Output capacity25³/h35³/h50³-60³/h75³/h
Overall power40kw60kw85kw105kw
Discharge height3800mm
Max. hauling speed40km/h
warranty13months after commissioning
After-sale serviceGuidance on erecting, commissioning and operator training, 24/7 technical assistance afterwards
Concrete mixerJS500JS750JS1000JS1500
Motor power18.5kw30kw18.5kwX230kwX2
Max. aggregate dia.80mm
Aggregate batcherPLD800PLD1200PLD1600PLD2400
Aggregate weighing precision±2%
Aggregate feederBelt conveyor
Other scale scopeCement±1%
water±1%
additive±1%
Control systemAuto computer control, 1 set
Pneumatic system1 set
